TECHNICAL SPECIFICATIONS |
GAS TYPES |
Chlorine (Cl2), Chlorine dioxide (ClO2), Hydrogen sulphide (H2S). Hydrogen cyanide (HCN), Hydrogen (H2) |
Source Life | 50 or 100 hours |
Accuracy | ±10% |
Repeatability | ±5% |
MECHANICAL |
Weight | 1,360g |
Size | 127(W) x 98.55(H) x 79.5(D) mm |
Tubing (Supplied) | 1.5 m long x 6.35 mm dia Teflon Lined hose |
Flow Rate | Range 0.2 @ 1.0 LPM |
Ultraviolent Light Source Lifespan | 500 hours of operation (Should be factory calibrated every 100 hours or annually) |
ELECTRICAL |
Power Source | 4 alkaline AA batteries |
Battery Life | approximately 10 hours |
Warm-up Time | approximately 2 minutes |
USER INTERFACE |
Display | LCD display |
Push Buttons | SELECT and POWER push button type switches |
Menu Languages | English, French, German, Spanish |
ENVIRONMENTAL |
Operating Temperature | 0℃ to 50℃ (32℉ to 122℉) |
Humidity | 0 - 100% RH (intermittent use) |
CERTIFICATIONS |
Conforms to : EC Directive 89/336/EEC in accordance with the provisions Statutory Instrument 2372 Conforms to : EN 50081-1 and EN 50082-1 |
